The details of the scaffolding machine

3,1 Passived Decoiler
Decoiler: decoiler, Inner expanding type, capacity:5T
Inner diameter material roll: ¢480~¢520mm
Outter diameter material roll: ≤1500mm

3,2 Leveler
Motor: 7.5KW Frequency conversion motor

3,3 Servo Feeding machine
Drive: 4 kw Servo motor


3,4 Punching machine
punching press: JF21-110
Maximum press: 110tons
Material of mould: Material:Cr12Mov, Quenching,Hardness:HRC58-62º
Quantity of punching dies:1sets

3,5 Main Roll Forming machine

1. Working speed :8-12 m/min

2. Material thickness :1.0-1.2mm

3. Control system:PLC

4. Decoiler :5T

5. Punching :one set

6. Main roll forming rollers:16row rollers

7. Roll material:GCR15 Steel after quenching process HRC58-62℃,he chrome plating surface treatment

8. Material of the shaft and the shaft diameter:45# steel processing, shaft diameter is 70mm

9. Main machine power :18.5kw

10. Hydraulic station power:5.5kw

11. Hydraulic pressure:24Mpa

12. Scissors punching material:Cr12Mov,Quenching HRC 58-62℃

13. Length tolerance:3m±1.0mm

14. Voltage :380V, 50HZ,3 phrase

15. driving mode :chain driving mode

16. Machine size :16.5*2.2*1.6m

17. Rolling speed:12-15m/min

18. Shaft diameter:Φ76mm

19. Material of cutting:Cr12Mov with quench HRC58-62°

20. Tolerance:10m+-0.5mm

21. Hydraulic station:5.5kw

Technical Parameter

Main Machine Parameter

JIANGYIN BOSJ SCIENCE & TECHNOLOGY CO., LTD located in the Yangtz e Rive r Delta and the famous "China's first village" Jiangyin Huaxi Village. It is a professional manufacturer specializing in the developing and export of roll forming machine for metal roof tiles, wall sheets, C-shaped puline, Z-shaped purline, press brakes, highway guardrail and CNC plasma cutting machine. BOSJ has developed machinery and production methods to meet customers' increasing demand for profitability and new business opportunities.


BOSJ has a group of experienced senior engineers, technicians, they were from machinery, automatic control, power electronics, and other fields, and skilled workers ensure high quality products for customers with perfect quality management and testing systems. We're always able to meet your customized needs. From basic economical roll formers to the most complex, we fashion a solution to meet your company's production goals and budgets.


In line with enterprising spirit on 'sincerity originally" company, use CAD/CAM electromechanics integrated technology, in a conscientious and down-to-earth manner to devoted to new product new industrial research and development of new technology, it is accurate to regard time of fighting in time of price that the high-quality products are reasonable as, loyal service is very domestic and international every user.


Our products cover more than 20 provinces and cities in China and are also exported to Southeast Asia, the Middle East, African regions and North America.
