Product: Shelf column, Shelf crossbeam, Shelf stay rod, Shelf plywood etc
The supermarket shelves and the stocking shelves are used widely in
modern lives. With science developing, The rack shelves are divided
for below series: The drive in rack, the medium duty shelf and the
light duty shelving and cantilever racking, Mezzanine and carton
flow rack , pallet flow storage rack..
Determinant of Heavy Duty Pallet Racking design
1. The weight of your goods (trays, steel containers / boxes are
included)
2. The dimension of your goods together with pallets ( Length Width
Height )
3. The maximum height of your forklift and the available height of
your warehouse
4. The dimension of your forklift,if you have,please offer us,we
will consider this fact.
5. The fork direction,if you have,please offer us,we will consider
this fact.
6. The dimension of your warehouse
7. The path of the transportation
Shelf Rack Roll Forming Machine specification(All parameter can be
design as clients requirement)
1. suitable raw material:PPGI or colored steel
2. material thickness:0.3-0.8mm
3. roller material:high grade 45# Steel, quenched and heated process, surface with 0.05mm hard chrome
4. shaft material:Shaft Material: High Grade 45# steel, Heated and quenched HRC 45-50
5. shaft diameter:76mm
6. Material of Rack: complete welded structure of A3 steel plate 18mm
thickness
7. Material Of Blade: Cr12 with polished, heat treatment and quenched
HRC 60-62
8. Main power:7.5kw
9. Main axles material: High Grade 45# steel
10. Machine Frame stand: welded with 36 # I-steel
Main Machine Parameter
| NO. | Name | unit | parameter | remark |
1 | materials | type | | Mild steel,galvanized sheet | |
| Plate strength | Map | ≥350 | |
| Plate thickness | mm | 1.0~1.6 | |
| 2 | specification | mm |
See the pictures | |
| 3 | speed | m/min | 18 | |
| 4 | Material of the roller | | GCr15,Hardening treatment | |
| 5 | drive type | | Gear box | |
| 6 | power | kw | About 35.5 | |
| 7 | Electrical control system | | PCL frequency control | |
| 8 | Size(lengthXwidthXheight) | m | 20X4X3.9 | |
| Main Accessories |
| 1 | Decoiler | 1 set |
| 2 | Main Forming Machine | 1 set |
| 3 | Correction System | 1 set |
| 4 | Hydraulic Station | 1 set |
| 5 | Auto-Cutting system | 1 set |
| 6 | PLC Control System | 1 set |
| 7 | Run Out Table | 1 set |
| Technical Datas roll forming machine |
| 1 | Material width | As your regards |
| 2 | The effective width | As your regards |
| 3 | The thickness of Coil | 1.0-3.0mm or more |
| 4 | Application | Warehouse system |
| 5 | The overall dimensions | 6800mmX1500mmX1300mm |
| 6 | Total weight | 5 Tons |
| 7 | Main Power | 5.5 KW |
| 8 | Uncoiler | Manual Uncoiler |
| 9 | Inner diameter | 508--610mm |
| 10 | Outer diameter | 1200mm |
| 11 | Loading weight | 3T |
| 12 | Forming speed | 5-10m/min |
| 13 | Forming steps | 12 stations or more |
| 14 | Bracket | welded with 36 # I-steel |
| 15 | Material of Shafts | 45# steel with rough finished and then refined finished |
| 16 | Diameter of the Roll | 76mm |
| 17 | Material of Rolls |
high quality 45#steel coated with hard chromium 0.05
mm |
18 | Processing Technology | rough processing ---refined processing--Hard Chromium Plating. |
| 19 | Material of Rack |
complete welded structure of A3 steel plate 16mm
thickness |
20 | Transmission | Transmitted by the chain-bracket/ Gearbox T180 |
| 21 | Material of Chain | 45#steel with heat treatment of HRC45-50° |
| 22 | Holders under chain for lubricant | By the machine |
| 23 | Material of cutting blade | Cr12 with quenched treatment 60-62 |
| 24 | Cutting system | Hydraulic cutting |
| 25 | Voltage | 380V/50HZ/3phase |
BOSJ offer you the full range warehouse system products,BOSJ has a
profesional engineering and production team to work with you.
